Haskel 8AAD-2 Air Amplifier

Haskel 8AAD-2 Air AmplifierFeatures & Benefits:Long seal life and easy maintenanceNo heat, flame or spark riskWide range of models, controls and optionsNo air line lubrication required, eliminating oily exhaustInfinitely variable outlet pressure and flow capabilityWide range of standard and custom systemsControl of maximum pressure by means of inexpensive air drive pressure regulatorsTechnical Data:Air Drive Size: 8 in1st Stage Ratio: 2:12nd Stage Ratio: N/AMin Gas supply pressure: 25 psiMax Gas supply pressure: 300 psiMax rated outlet pressure: 300 psiStatic outlet stall pressure formula: Pa Ps (Pa = air drive pressure, Ps = GAS supply pressure)Min AIR drive pressure: 40 psiMax AIR drive pressure: 130 psiPhysical Characteristics:Unit weight: 90 lbs.Displacement / cycle: 400 cu. in.Max cycles: 50/min.GAS inlet/outlet connections: 1″ FNPT (both)AIR drive inlet port: 3/4″ FNPTHaskel 8AAD-2 Air Amplifier Repair kit information:Boosting section seal kit P/N: N/AAir drive section seal kit P/N: 58710Air valve seal kit P/N: 50881Optional tools: 28584 (Sleeve removal tool); 58748 (Bullet tool for installing piston rod thru rod seals)Notes: Only one kit required: each kit contains all of the necessary seals for the Air Drive & Gas Section or Air Drive & Air Valve. Units manufactured before Jun. 1999 use Air Valve seal kit P/N 51396-2.Optional Modifications:C-18: Air filter, regulator with gauge, and manual start/stop29125: External pilot modification50341: Low permeability seals for CO2 gas service82500: ATEX modification To add any modifications to this air amplifier or for assistance in selecting the right air amplifier for your application, please contact our Sales Department for assistance.   Product Catalog: Air Amplifier Catalog  Installation Documents: SKIS-001  SKIS-002  SKIS-014
