Haskel AA-15 Air Amplifier

Haskel AA-15 Air AmplifierFeatures & Benefits:Long seal life and easy maintenanceNo heat, flame or spark riskWide range of models, controls and optionsNo air line lubrication required, eliminating oily exhaustInfinitely variable outlet pressure and flow capabilityWide range of standard and custom systemsControl of maximum pressure by means of inexpensive air drive pressure regulatorsTechnical Data:Air Drive Size: 5.75 in1st Stage Ratio: 15:12nd Stage Ratio: N/AMin Gas supply pressure: 50 psiMax Gas supply pressure: 2250 psiMax rated outlet pressure: 2250 psiStatic outlet stall pressure formula: 15 Pa (Pa = air drive pressure, Ps = GAS supply pressure)Min AIR drive pressure: 40 psiMax AIR drive pressure: 150 psiPhysical Characteristics:Unit weight: 27 lbs.Displacement / cycle: 6.2 cu. in.Max cycles: 80/min.GAS inlet/outlet connections: 1/4″ FNPTAIR drive inlet port: 1/2″ FNPTHaskel AA-15 Air Amplifier Repair kit information:Boosting section seal kit P/N: 17550Air drive section seal kit P/N: 16772Air valve seal kit P/N: 16771Optional tools: 28584 (Sleeve removal tool)Notes: None.Optional Modifications:C-5, 6 or 7: Air filter, regulator with gauge, and manual start/stop29376: Three-way cycling spool50341: Low permeability seals for CO2 gas service51050: Extreme service cycling modification82500: ATEX modification To add any modifications to this air amplifier or for assistance in selecting the right air amplifier for your application, please contact our Sales Department for assistance.   Product Catalog: Air Amplifier Catalog  Installation Documents: SKIS-001  SKIS-002  SKIS-014
